DCS 75Ah Deep Cycle LFP Battery

$825.00
$825.00
SKU: DCS-12V-75AH

Description:

THE BMS

DCS LFP Batteries are engineered to perform in the most harsh operating conditions. Every DCS LFP battery features DCS own custom and proprietary BMS that has been continuously refined and improved up since it was first introduced in 2018. The DCS 3S BMS is paired with our stand-alone DCS 16 channel 59.2A Active Cell Balancing System. Both have been designed to pass MIL-STD-810G (Method 514.6) vibration testing requirements which ensures that these batteries remain reliable even in the most punishing of conditions.

THE APP

All DCS LFP batteries also feature our comprehensive Bluetooth system that in conjunction with the DCS LFP App displays the following:

• Battery pack Voltage.
• State of Charge (SOC) % estimate via impedance tracking.
• Amp meter displaying real time charge and discharge current.
• Time remaining (estimate in real time).
• BMS Mosfet temperature status (for winching or large inverter loads).
• Battery pack cycle count.
• Cell status showing real-time active balancing operation.
• More accurate data compared to external battery monitors (shunts).

THE BATTERY

The DCS 75Ah is a compact battery in a sealed, flame retardant ABS plastic enclosure with a small footprint that delivers 750 Lithium Cranking Amps (LCA) and has a 2C charge rate which means this battery can run up to an 1800W inverter.

THE CYCLE PERFORMANCE

This Battery is rated to achieve a minimum of 2500 cycles @ 100% DOD (when ≤ 80% of its original capacity retention has been reached @ 77F). That means that this battery is rated to achieve at least 2500 cycles by the time it has faded 20% from its original capacity, that is, when ≤ 80% of its original capacity retention has been reached.



Features:

• Mil-Spec Vibration tested BMS for maximum durability, safety and longevity.
• Engine Starting Capable.
• High Charge and Discharge Rates (See Data Sheet).
• Guaranteed Grade A - DCS Cylindrical Cells.
• DCS App with Bluetooth 4.0 Data Monitoring.



Specifications:



  • Nominal Voltage: 12V
  • Nominal Capacity: 75Ah
  • Dimensions: 10.236” x 6.653” x 6.889”
  • Weight: 18.9 lbs
  • Terminal Type: M8 Stainless Steel / Copper
  • Cell Type: Cylindrical Cells - 3.2V (15Ah)
  • Cell Chemistry: Lithium Ferro Phosphate Cells (LFP)
  • Cell C-Rate Specification: 2C
  • Cycle Performance: 2500 Cycles @ 100% DOD (when ≤ 80% Capacity Retention has been reached @ 77F).
  • Max Charge Voltage: 14.6V
  • Recommended Charge Current: ≤ 50A (0.7C)
  • Max Charge Current: ≤ 75A (1.0C)
  • Max Discharge Current: ≤ 150A (2.0C)
  • BMS Type: DCS 3S 150A
  • Lithium Cranking Amps: 750 LCA
  • Ingress Protection: IP54
